Removal Procedure

  1. Grasp the front edge and the lower rear edge of the console trim panel (1).
  2. Pull the trim panel outward in order to disengage the retainers.
    Fig 1: Removing Auxiliary Power Outlet Electrical Connector & Trim Panel - Left
    G01796405Courtesy of GENERAL MOTORS CORP.
