Ford Motor Co.
- If equipped with Moon Roof, halo moulding must first be removed. Push sun shade to rear and open roof panel half way. Remove screws on forward portion of moulding.
- On Lincoln and Mark V, lower front edge of halo moulding and cycle sliding panel fully closed. Loosen both screws retaining one rear slide, move slide inboard and unsnap it from the track. Turn halo moulding sideways and down to remove.
- On all models except Lincoln & Mark V, cycle roof to a nearly closed position. Pull the forward center of halo moulding downward until the horizontal tabs are removed from track.NOTE: Place a shop towel over front horizontal tabs to prevent them from tearing headliner.
Cycle roof to fully closed position. Slide moulding forward. Pull rearward on center section so horizontal track slide is removed from track. Slide halo moulding forward and out. To install halo moulding, reverse removal procedure.
- To remove the sun shade on Lincoln and Mark V, place sliding panel in rearmost position (with halo moulding removed). Pull shade forward, bow shade upward at center, then lift shade out of tracks.
- To remove sun shade on all models except Lincoln and Mark V, first remove halo as previously described and sliding panel as follows, then from outside the vehicle push center of shade upward to disengage shade from track and slide shade forward and out of vehicle.
- To remove sliding panel (metal or glass) first remove halo moulding. Detach sliding panel from both left and right front slide assemblies by removing outboard retaining screw from guide shoe. Loosen inboard screw, rotate guide shoe so slide portion is disengaged from track, then proceed as follows.
- On Lincoln and Mark V, rotate rear slide tension springs to inboard position to release them. Detach panel from rear slide assemblies by removing the two retaining screws and removing mounting bracket to panel retainers from tabs in panel.
- On all models except Lincoln and Mark V, grasp panel rear retainer pins and slide pins inboard to disengage it from pivot bracket. Rotate pins away from pivot bracket and from outside vehicle, remove sliding panel.
