E5FA Rear Combination Lamp - Liftgate Right (-Y6S)
 Courtesy of GENERAL MOTORS COMPANY
|
Connector Part Information
- Harness Type: Liftgate Right
- OEM Connector: 6098-8997
- Service Connector: Service by Harness - See Part Catalog
- Description: 6 - Way F 1.2 Series (GY)
|
Terminal Part Information
| Terminal Type ID |
Terminated Lead |
Diagnostic Test Probe |
Terminal Removal Tool |
| I |
Not required |
J-35616-16 (LT GN) |
No Tool Required |
| Pin |
Size |
Color |
Circuit |
Function |
Terminal Type ID |
Option |
| 1 |
0.75 |
BK |
2950 |
Ground |
I |
-Y6S |
| 2 |
0.5 |
BN / GY |
6995 |
Right Rear Park Lamp Control |
I |
-Y6S |
| 3 |
0.5 |
WH / YE |
7541 |
Right Rear Stop Lamp Control |
I |
-Y6S |
| 4 |
0.5 |
GN / WH |
1324 |
Backup Lamp Control |
I |
-Y6S |
| 5 |
0.5 |
BU / VT |
1335 |
Right Rear Turn Signal Lamp Control 2 |
I |
-Y6S |
