E5EA Rear Combination Lamp - Liftgate Left (Y6S)
 Courtesy of GENERAL MOTORS COMPANY
|
Connector Part Information
- Harness Type: Liftgate Left
- OEM Connector: 6098-8444
- Service Connector: Service by Harness - See Part Catalog
- Description: 8 - Way F 1.2 Series (GY)
|
Terminal Part Information
| Terminal Type ID |
Terminated Lead |
Diagnostic Test Probe |
Terminal Removal Tool |
| I |
Not required |
J-35616-16 (LT GN) |
No Tool Required |
| Pin |
Size |
Color |
Circuit |
Function |
Terminal Type ID |
Option |
| 1 |
0.75 |
BK |
2350 |
Ground |
I |
Y6S |
| 2 |
0.5 |
BN / BU |
6993 |
Left Rear Park Lamp Control |
I |
Y6S |
| 3 |
0.5 |
GY / YE |
7542 |
Left Rear Stop Lamp Control |
I |
Y6S |
| 4 |
0.5 |
GN / WH |
24 |
Backup Lamp Control |
I |
Y6S |
| 5 |
0.5 |
BU / WH |
1334 |
Left Rear Turn Signal Lamp Control 2 |
I |
Y6S |
| 7 |
0.75 |
YE / GN |
2024 |
Animation Lighting Control |
I |
Y6S |
| 8 |
0.75 |
RD / GN |
3840 |
Battery Positive Voltage |
I |
Y6S |
