Section 143 (Engine Mechanical - 3.6L (LGX) - Repair Instructions)
>>
Repair Instructions
>>
Water Outlet Removal
Water Outlet Removal
WARNING:
This page is about a different car, the 2020 Buick Regal and 2019 Buick Regal. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of GENERAL MOTORS COMPANY
Callout
Component Name
1
Engine Coolant Air Bleed Pipe [2x]
2
Engine Coolant Air Bleed Pipe Bolt
3
Water Outlet Bolt
4
Water Outlet
