Rear Wheel Bearing and Hub Replacement (GNE)

Preliminary Procedures

1. Remove the rear tire and wheel. Refer to Tire and Wheel Removal and Installation .
2. Remove the rear wheel speed sensor. Refer to Rear Wheel Speed Sensor Replacement .
3. Separate the wheel drive shaft from the knuckle. Refer to Rear Wheel Drive Shaft Replacement .
4. Remove the rear brake rotor. Refer to Rear Brake Rotor Replacement .
5. Remove the rear spring. Refer to Rear Spring, Insulator, and Jounce Bumper Replacement .
6. Remove lower control arm bolt and nut from the rear wheel hub bracket. Refer to Rear Suspension Control Arm Replacement .

1. First Pass: 90 N.m (66 lb ft)
2. Final Pass: plus 75 degrees
