Section 9 (Hybrid/EV Control System)
>>
Schematic Wiring Diagrams
>>
Hybrid/EV Controls Wiring Schematics
>>
Brake Apply and Drive Motor Control
Brake Apply and Drive Motor Control
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Brake Apply and Drive Motor Control
Courtesy of GENERAL MOTORS COMPANY
