Fuel Pump Cover Replacement
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| Preliminary Procedure Disconnect electrical wiring harness from fuel pump cover. |
|
| 1 | Fuel Pump Cover Fastener
CAUTION:
Refer to Fastener Caution . Tighten 10 N.m (89 lb in) |
| 2 | Fuel Pump Cover |
| 3 | Fuel Pump Insulator |
| 4 | Fuel Injector Fuel Rail Noise Shield |
