Exhaust Manifold and Components
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | Secondary Air Injection Check Valve Gasket |
| 2 | Secondary Air Injection Check Valve Assembly |
| 3 | Secondary Air Injection Check Valve Bolt |
| 4 | Secondary Air Injection Assembly Stud |
| 5 | Secondary Air Injection Check Valve Pipe Adapter |
| 6 | Secondary Air Injection Check Valve Nut |
| 7 | Secondary Air Injection Check Valve Pipe Adapter |
| 8 | Secondary Air Injection Check Valve Pipe Adapter Bolt |
| 9 | Exhaust Manifold Gasket |
| 10 | Exhaust Manifold Heat Shield Bolt |
| 11 | Exhaust Manifold Heat Shield |
| 12 | Oxygen Sensor |
| 13 | Block Heater |
| 14 | Block Heater Bolt |
| 15 | Exhaust Manifold |
| 16 | Exhaust Manifold Nut |
| 17 | Exhaust Manifold Stud |
| 18 | Secondary Air Injection Check Valve Pipe Adapter Bracket |
| 19 | Secondary Air Injection Check Valve Pipe Adapter Bolt/Stud |
