Removal Procedure

    Fig 1: Positive Battery Cable Terminal, Nut And Fuse Block Cover
    GM2195932Courtesy of GENERAL MOTORS COMPANY
  1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
  2. Open the battery fuse block cover (1).
  3. Remove the battery positive fastener (2) from battery fuse block and detach retainers from the battery tray.
    4. Fig 2: Battery Negative Nut & Terminal
    GM2202529Courtesy of GENERAL MOTORS COMPANY
  4. Remove the battery negative fastener (1) and terminal (2) from the left front frame rail.
    5. Fig 3: Battery Positive Cable Terminal And Fastener
    GM2680835Courtesy of GENERAL MOTORS COMPANY
  5. Remove the battery negative ground fastener (1) and remove the battery negative terminal (2).
  6. Remove the starter solenoid fastener (3) and battery positive cable terminal (4) from the starter solenoid.
    7. Fig 4: Generator Fastener And Battery Positive Terminal
    GM2680837Courtesy of GENERAL MOTORS COMPANY
  7. Remove the generator fastener (1) and the battery positive terminal (2) from the generator.
    8. Fig 5: Battery Positive And Negative Cable
    GM2680838Courtesy of GENERAL MOTORS COMPANY
    NOTE:

    Observe how the battery positive and negative cable was routed within the engine compartment.

  8. Remove the battery positive and negative cable (1) from the engine compartment.
