Rear Compartment Floor Panel Trim Replacement (With Blower Cover, HP6)
| Callout | Component Name |
|---|---|
| 1 | Rear Compartment Side Trim Panel (Push-In) Retainer (Qty:4) Procedure Pull the rear seat back cushion latch release located on the top of the rear seat back cushion, and fold the rear seat back cushion forward to access two of the (Push-in) retainers. The other two can be accessed thru the rear compartment.
NOTE:
When reinstalling lower interior push-in retainer, lift seat 4045 degrees above flat to gain sufficient hand room to get retainer seated. |
| 2 | Rear Compartment Floor Panel Trim Assembly (with Blower Cover, HP6) |
| Callout | Component Name |
|---|---|
| 1 | Rear Compartment Side Trim Panel (Push-In) Retainer (Qty:4) Procedure Pull the rear seat back cushion latch release located on the top of the rear seat back cushion, and fold the rear seat back cushion forward to access two of the (Push-in) retainers. The other two can be accessed thru the rear compartment.
NOTE:
When reinstalling lower interior push-in retainer, lift seat 4045 degrees above flat to gain sufficient hand room to get retainer seated. |
| 2 | Rear Compartment Floor Panel Trim Assembly (with Blower Cover, HP6) |
