Headliner Harnesses

Harness Routing Views

Headliner Harness (CF5)




1 - X390
2 - Dome/Reading Lamp - Left Connector
3 - Headliner
4 - X317
5 - Inside Rearview Mirror (ISRVM) Connector
6 - Reading Lamp Overhead Console
7 - X318
8 - X398
9 - J394
10 - J393
11 - J398
