Air Outlet Replacement - Instrument Panel - Left

Fig 1: Identifying Instrument Panel Outer Air Outlet - Left Side

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications
1	Instrument Panel Outer Air Outlet - Left Tip: Using a flat-bladed tool release, the headlamp bezel assembly from the instrument panel. Disconnect the headlamp electrical connector.
2	Using a flat-bladed tool release, the air outlet from the headlamp bezel.
