Removal Procedure

WARNING: This page is about a different car, the 2006 Pontiac Montana SV6, 2006 Chevrolet Uplander, and 2006 Buick Terraza. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information.
    2. Fig 1: Removing/Installing Transmission Brace
    GM1544756Courtesy of GENERAL MOTORS CORP.
  2. Remove the transaxle brace (4). Refer to Automatic Transmission Brace Replacement (Front Wheel Drive)  or Automatic Transmission Brace Replacement (All Wheel Drive)  or Automatic Transmission Brace Replacement (Front Wheel Drive and All Wheel Drive) .
    3. Fig 2: Identifying Torque Converter Cover Bolts
    GM289471Courtesy of GENERAL MOTORS CORP.
  3. Remove the torque converter cover bolts.
  4. Remove the torque converter cover.
