Removal Procedure

WARNING: This page is about a different car, the 2006 Pontiac Montana SV6, 2006 Chevrolet Uplander, and 2006 Buick Terraza. However, it is still accessible from the selected car via links, so may be relevant.

Remove the front door water deflector. Refer to Water Deflector Replacement - Front Door .

Fig 1: View Of Speaker Assembly

Courtesy of GENERAL MOTORS CORP.

Remove the front door speaker. Refer to Speaker Replacement - Front .

Fig 2: Locating Front Door Window Run Channel Screws

Courtesy of GENERAL MOTORS CORP.

Remove the front door window run channel screws.

Fig 3: View Of Front Door Window Run Channel

Courtesy of GENERAL MOTORS CORP.

Remove the front door window run channel from the front door window weatherstrip.
Remove the front door window run channel from the front door.
