Harness Routing Views

Fig 1: Harness (Rear of the Engine - L26)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 1

Callout	Component Name
1	C101
2	Evaporative Emission (EVAP) Canister Purge Solenoid
3	Fuse Block - Underhood C1
4	C104
5	Wheel Speed Sensor (WSS) - RF Connector
6	Engine Oil Pressure (EOP) Sensor Connector
7	Heated Oxygen Sensor (HO2S) Connector
8	Wheel Speed Sensor (WSS) - LF Connector
9	C100
10	S113 (NU3)
11	Electronic Brake Control Module (EBCM) Connector

Fig 2: Harness (Front of the Engine - L26)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 2

Callout	Component Name
1	Fuse Block - Underhood C1
2	C110
3	S109
4	C126
5	S102
6	Throttle Actuator Control (TAC) Module Connector
7	S101
8	C101
9	Electronic Brake Control Module (EBCM) Connector
10	S117 (NU3)
11	Powertrain Control Module (PCM) C2 Connector
12	Powertrain Control Module (PCM) C3 Connector
13	Powertrain Control Module (PCM) C1 Connector
14	C100
15	Wheel Speed Sensor (WSS) - LF Connector
16	S114 (NU3)
17	G115 (NU3)
18	G115 (JL9)
19	Wheel Speed Sensor (WSS) - RF Connector
20	C104

Fig 3: Harness (Driver Door Frame and Trim)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 3

Callout	Component Name
1	Door Frame
2	Door Trim Panel
3	Door Latch Connector
4	S502
5	S501
6	C501
7	C260
8	S500

Fig 4: Harness (Passenger Door Frame and Trim)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 4

Callout	Component Name
1	Door Trim Panel
2	Door Frame
3	S604
4	C261
5	C601
6	S605
7	Door Latch Connector

Fig 5: Harness (Object Sensor and License Lamp)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 5

Callout	Component Name
1	Rear Fascia
2	C450
3	S450
4	S451
5	S401
6	S402
7	C406

Fig 6: Harness (Headliner Harness - CF5)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 6

Callout	Component Name
1	C390
2	Dome/Reading Lamp - Left Connector
3	Headliner
4	C317
5	Inside Rearview Mirror (ISRVM) Connector
6	Reading Lamp Overhead Console
7	C318
8	C398
9	S394
10	S393
11	S398

Fig 7: Harness (Steering Column)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 7

Callout	Component Name
1	Steering Angle Sensor
2	C201
3	A/T Shiftlock Solenoid Connector
4	Horn Switch Connector
5	C277
6	Steering Wheel Controls
7	Multifunction Accessory Switch
8	Body Control Module (BCM) Connector

Fig 8: Harness (Driver Seat)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 8

Callout	Component Name
1	Seat Belt Pretensioner - Left
2	Lumbar Motor
3	S330
4	Lumbar Adjuster Switch - Driver
5	Seat Adjuster Switch - Driver
6	S331
7	Heated Seat Relay
8	C311
9	C316
10	Seat Adjuster Motor Assembly Connector

Fig 9: Harness (Rear Body)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 9

Callout	Component Name
1	C402
2	C450
3	C390
4	S360
5	S361
6	Rear Object Sensor Control Module Connector (UD7)
7	C401
8	C406
9	Evaporative Emission (EVAP) Canister Vent Solenoid Valve
10	Rear Floor Pan
11	C405
12	S420
13	S407
14	C400

Fig 10: Harness (Console)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 10

Callout	Component Name
1	Auxiliary Power Outlet
2	C240

Fig 11: Harness (Passenger Seat)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 11

Callout	Component Name
1	C313
2	Inflatable Restraint Passenger Presence System (PPS) Module
3	S333

Fig 12: Harness (LR Door)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 12

Callout	Component Name
1	Window/Door Lock Switch Connector
2	Door Frame
3	Door Lock Actuator
4	Door Trim Panel
5	Window Motor Connector
6	C355

Fig 13: Harness (RR Door)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 13

Callout	Component Name
1	Door Frame
2	Window/Door Lock Switch Connector
3	C356
4	Window Motor
5	Door Trim Panel
6	Door Latch Assembly Connector

Fig 14: Harness (Front of the Engine - LY7)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 14

Callout	Component Name
1	C107
2	S121
3	S120
4	S110
5	S119
6	C109
7	S103
8	S131
9	S133
10	G131
11	Engine Coolant Temperature (ECT) Sensor
12	Starter Solenoid
13	Starter
14	Engine Oil Pressure (EOP) Sensor

Fig 15: Harness (Rear Cylinder Head - LY7)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 15

Callout	Component Name
1	Cylinder Block
2	Throttle Actuator Control (TAC) Module Connector
3	S108
4	Engine Control Module (ECM) C1 Connector
5	C107
6	G115
7	S131
8	S130
9	G130

Fig 16: Harness (Front Body)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 16

Callout	Component Name
1	C356
2	C241
3	C240
4	C355
5	C208
6	Body Control Module (BCM) C2
7	S303
8	C301
9	G301
10	S350
11	C311
12	C313
13	G302
14	C302
15	Fuse Block - I/P C2
16	C200
17	C278
18	S300
19	Inflatable Restraint Sensing and Diagnostic Module (SDM)
20	S406

Fig 17: Harness (Forward Lamp)

Courtesy of GENERAL MOTORS CORP.

Callouts For Fig 17

Callout	Component Name
1	Fuse Block - Underhood C3
2	S112
3	C145
4	C141
5	C143
6	G101
7	Cooling Fan - Left Connector
8	Cooling Fan - Right Connector
9	G100
10	C142
11	C144
12	C146
13	S124
