Secondary Timing Chain Tensioner Shoe Replacement - Right

SECONDARY TIMING CHAIN TENSIONER SHOE REPLACEMENT - RIGHT

Removal Procedure





1. Remove the engine front cover. Service and Repair

2. Remove the right bank secondary camshaft drive chain tensioner. 22. Secondary Timing Chain Tensioner Removal - Right

3. Remove the right bank secondary camshaft drive chain shoe. 23. Secondary Camshaft Drive Chain Shoe Removal - Right

Installation Procedure





1. Install the right bank secondary camshaft drive chain shoe. 126. Secondary Camshaft Drive Chain Shoe Installation - Right

2. Install the right bank secondary camshaft drive chain tensioner. 127. Secondary Timing Chain Tensioner Installation - Right

3. Install the engine front cover. Service and Repair
