Connecting the bleeder unit for brake fluid (after repair, top up brake fluid)
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2023 BMW M240i xDrive, 2023 BMW M240i, 2023 BMW 230i xDrive, 2023 BMW 230i, and 2022 BMW M240i xDrive. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
TECHNICAL INFORMATION
Use only BMW-approved brake fluids; see "Fluid Capacities" tab for the selected vehicle.
Use only BMW-approved brake fluids; see "Fluid Capacities" tab for the selected vehicle.
NOTE:
RISK OF DAMAGE
Paint damage.
Mechanical or chemical action may lead to paint damage.
Paint damage.
Mechanical or chemical action may lead to paint damage.
- Cover up working area with specified covering material only.
- Connect the bleeder unit (1) to the brake fluid reservoir and turn on.
Observe the operating instructions of the corresponding equipment manufacturer.
- Top up the brake fluid level to the maximum mark.
The tire pressure must not exceed 2 bar.
