Installing the center rear seat backrest

Precondition

Center rear seat backrest folded

• Position the center rear seat backrest (1) at an angle of 90° to the left rear seat backrest (2).
• Install the center rear seat backrest (1) in the arrow direction.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Position the center bearing bracket (2) correctly.
• Replace screws (1).

  Parts:  Screws

• Tighten the screws (1).
  TIGHTENING TORQUE SPECIFICATIONS



  Rear seat backrest on body
  screw Replace screw.	Tightening torque	42 Nm

  Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up work

• Refer to INSTALLING LUGGAGE COMPARTMENT FLOOR COVERING .
• Refer to INSTALLING THE REAR SEAT BACKREST .
• Refer to INSTALLING RIGHT BACKREST SIDE SECTION .
• Refer to INSTALLING THE REAR SEAT .
