Removing the shaft for the backrest upper section adjustment on the front seat
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2023 BMW M5, 2022 BMW M5, 2021 BMW M5, 2020 BMW M5, and 2019 BMW M5. However, it is still accessible from the selected car via links, so may be relevant.
Preliminary work
- Refer to REMOVING THE TOP REAR PANEL FROM THE FRONT SEAT REAR PANEL .
- Refer to REMOVING THE REAR PANEL AT THE BOTTOM OF THE FRONT SEAT REAR PANEL .
- Loosen the seat cover (1) in the marked area.
- Unclip the cover (1) towards the inside.
- Pull out the shaft (2) from the motor and gears and remove it.
