Remove the external radiator on the right
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2023 BMW M5, 2022 BMW M5, 2021 BMW M5, 2020 BMW M5, and 2019 BMW M5. However, it is still accessible from the selected car via links, so may be relevant.
WARNING:
Hot surfaces.
Risk of burning!
Risk of burning!
- Perform all work only on components that have cooled down.
WARNING:
Hot fluids.
Risk of scalding!
Risk of scalding!
- Conduct all work in the vehicle wearing appropriate personal protective equipment only.
NOTE:
TECHNICAL INFORMATION
Collect and dispose of emerging fluids. Observe country-specific waste disposal regulations.
Collect and dispose of emerging fluids. Observe country-specific waste disposal regulations.
Preliminary work
- Refer to REMOVING FRONT RIGHT WHEEL .
- Refer to REMOVING THE FRONT RIGHT LOWER WHEEL ARCH COVER .
- Refer to REMOVING THE FRONT RIGHT WHEEL ARCH COVER FRONT SECTION .
NOTE:
TECHNICAL INFORMATION
Collect and dispose of emerging fluids. Observe country-specific waste disposal regulations.
Collect and dispose of emerging fluids. Observe country-specific waste disposal regulations.
If installed: Removing the right cross-member
- Loosen screws (1).
- Remove the right cross-member (2).
NOTE:
Description is for left component only. Procedure on the right side is identical.
- Disengage the retaining clips (1) with a suitable screwdriver.
- Slide the coolant line (2) towards the rear.
- Drain coolant.
NOTE:
Description is for left component only. Procedure on the right side is identical.
- Loosen screw (1).
- Loosen screw (2).
- Remove the radiator (4) with the holder (3) from the rubber mounts diagonally upwards towards the rear.
