51 13... Replacing bracket for roof luggage rack on left or right

WARNING: This page does not describe the selected car, but rather 16 other vehicles, including the 2006 BMW 330Ci, 2005 BMW 330xi, 2005 BMW 330i, 2005 BMW 330Ci, and 2004 BMW 330xi. However, it is still accessible from the selected car via links, so may be relevant.

Remove and install trim strip on roof frame on left or right, refer to REMOVING AND INSTALLING TRIM STRIP ON ROOF FRAME AT LEFT OR RIGHT .

Remove body sealing compound (1) with special tool 00 9 322 and unfasten threaded pin (2).

Fig 1: Removing Body Sealing Compound

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Threaded pin may not be wetted with screw securing adhesive on screw-in thread (1).
Before installing threaded pin, protect body against corrosion (e.g. apply zinc dust paint).
Tightening Torque. Refer to BODY EQUIPMENT - TIGHTENING TORQUES .

Fig 2: Installing Threaded Pin

Courtesy of BMW OF NORTH AMERICA, INC.

Apply body sealing compound (1) (Terostat 9320, sourcing reference: BMW Parts Service).

After hardening time of body sealing compound (1), use a paint pencil of corresponding car color to paint over body sealing compound (1) and threaded bolt (2).

Fig 3: Using Paint Pencil Of Corresponding Car Color To Paint Over Body Sealing Compound

Courtesy of BMW OF NORTH AMERICA, INC.
