51 32 211 Replacing front left or right rubber guide for left or right door window

WARNING: This page does not describe the selected car, but rather 16 other vehicles, including the 2006 BMW 330Ci, 2005 BMW 330xi, 2005 BMW 330i, 2005 BMW 330Ci, and 2004 BMW 330xi. However, it is still accessible from the selected car via links, so may be relevant.

Remove mirror on front door. See 51 16 000 Removing and installing/replacing rear-view mirror on left or right front door

NOTE: Remove cover from door window frame completely.
Open complete door window glass completely.

Remove sound insulation (1).

Fig 1: Removing Sound Insulation

Courtesy of BMW OF NORTH AMERICA, INC.

Release rivet (1).

Remove complete rubber guide (2) from front door (3).

Installation:

Coat rubber guide (2) with water prior to installation.

Insert rubber guide at front/bottom in window guide channel.

Fig 2: Removing Complete Rubber Guide From Front Door

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Sound insulation (1) must be fitted and must not be damaged.

Fig 3: Installing Sound Insulation

Courtesy of BMW OF NORTH AMERICA, INC.
