13 62 511 Replacing intake air temperature sensor (M52TU, M54)

WARNING: This page does not describe the selected car, but rather 16 other vehicles, including the 2006 BMW 330Ci, 2005 BMW 330xi, 2005 BMW 330i, 2005 BMW 330Ci, and 2004 BMW 330xi. However, it is still accessible from the selected car via links, so may be relevant.

Turn off ignition.

Remove cover from fuel injectors. See HOUSING COVER

Disconnect plug connection (1) for temperature sensor.

Fig 1: Disconnecting Plug Connection For Temperature Sensor

Courtesy of BMW OF NORTH AMERICA, INC.

Press catch and withdraw temperature sensor (1) from intake air manifold.

Installation:

Check sealing ring on temperature sensor for damage, replace if necessary.

Coat sealing ring with antiseize agent.

Fig 2: Removing Temperature Sensor From Intake Air Manifold

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Read out fault memory of DME control unit.
Check stored fault messages.
Rectify faults.
Then clear fault memory.
