63 99 273 Replacing bulb for turn indicator, front left

WARNING: This page does not describe the selected car, but rather 15 other vehicles, including the 2005 BMW 325xi, 2005 BMW 325i, 2005 BMW 325Ci, 2004 BMW 325xi, and 2004 BMW 325i. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Follow instructions for handling light bulbs (exterior lights), refer to 63 99... INSTRUCTIONS FOR HANDLING LIGHT BULBS (EXTERIOR LIGHTS) .

Coupe/Convertible From 03/2003:

Turn bulb holder for turn indicator bulb (1) in direction of arrow and pull out of headlight (2) towards rear.

Fig 1: Turning Bulb Holder For Turn Indicator Bulb

Courtesy of BMW OF NORTH AMERICA, INC.

Pull bulb for turn indicator (1) out of turn indicator bulb holder (2).

Fig 2: Pulling Bulb For Turn Indicator

Courtesy of BMW OF NORTH AMERICA, INC.

All Others:

Necessary Preliminary Tasks:

Remove complete front turn-signal lamp. 63 13 150 Removing and installing/replacing complete front left or right turn signal lamp
Remove bulb.
