61 31 295 Replacing clutch switch for cruise control system

WARNING: This page does not describe the selected car, but rather 16 other vehicles, including the 2006 BMW 325Ci, 2005 BMW 325xi, 2005 BMW 325i, 2005 BMW 325Ci, and 2004 BMW 325xi. However, it is still accessible from the selected car via links, so may be relevant.

Remove trim panel for pedal assembly. See 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY

Press clutch pedal with pedal support down to flow and lock in position.

Disconnect plug connection (1).

Withdraw sleeve (3) in direction of arrow up to stop.

Fig 1: Withdrawing Sleeve

Courtesy of BMW OF NORTH AMERICA, INC.

Press both retaining clips together at front end and pull out switch (2) in direction of arrow towards rear.

Installation:

Slowly move clutch pedal to initial position.
