Installing the rear brake pad wear sensor

• Install brake pad wear sensor (2) in the brake pad in the arrow direction and ensure that it fits correctly.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Hook the cable of the brake pad wear sensor into the holder (1).

  If the holder (1) is not available, then the holder (1) must be installed later!

  Courtesy of BMW OF NORTH AMERICA, INC.

• Hook the cable of the brake pad wear sensor into the holder (1).
• Connect and lock the connector and close the cover (2).

  Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up work

• Refer to MOUNTING THE REAR RIGHT WHEEL .
