Adjust charging voltage
WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2022 BMW M340i xDrive, 2022 BMW M340i, 2022 BMW 330i xDrive, 2022 BMW 330i, and 2022 BMW 330e xDrive. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
TECHNICAL INFORMATION
Please comply with instructions in Owner's Manual.
Please comply with instructions in Owner's Manual.
- Prior to commencing work: Adjust the charging voltage of the new cell module in the removed condition to the charging voltages of the cell modules in the high-voltage battery of the vehicle. Use the cell module charger 2 359 907 for this purpose.
- Cell modules must be charged individually . Do not charge multiple cell modules at the same time.
- Only with high-voltage battery units with dual-cell modules: Double cell modules consist of two fixed single cell modules. The dual-cell modules may only be charged individually. Before charging, the module connection between the modules may also have to be removed. Disconnecting the dual module screw connection is not permitted.
- List of charging cables:
101:2 405 036
112, 115:2 405 037
F15PHEV, F30PHEV, F45PHEV, F48PHEV, F60PHEV, F39PHEV: 2 409 403
GxxPHEV, G38PHEV, 115, F45PHEV LCI, F48PHEV LCI, F60PHEV LCI, F39PHEV LCI: 2 458 279
F49PHEV, M13:2 446 694
F49PHEV LCI, M13 LCI: 5A19 218
F56BEV :2 471 410
G08, 120-SE11: 5 A2A 424, 5 A2A 421, 5 A2B 528
