Lights -- Repair (F91, F92 & F93)
>>
63 31 Interior Lighting
>>
63 31 085 Removing and installing/replacing trunk compartment light (trunk lid)
>>
Install trunk compartment light
Install trunk compartment light
Connect connector
(1)
with the trunk light
(2)
.
Courtesy of BMW OF NORTH AMERICA, INC.
Position the luggage compartment lamp
(1)
and install in the tailgate trim panel
(2)
.
Courtesy of BMW OF NORTH AMERICA, INC.
