Connecting the bleeder unit for brake fluid (after repair, top up brake fluid)
WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2022 BMW M340i xDrive, 2022 BMW M340i, 2022 BMW 330i xDrive, 2022 BMW 330i, and 2022 BMW 330e xDrive. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
TECHNICAL INFORMATION
Use only BMW-approved brake fluids.
Use only BMW-approved brake fluids.
NOTE:
RISK OF DAMAGE
Paint damage .
Mechanical or chemical action may lead to paint damage .
Paint damage .
Mechanical or chemical action may lead to paint damage .
- Cover up working area with specified covering material only.
- Connect the bleeder unit (1) to the brake fluid reservoir and turn on.
Observe the operating instructions of the corresponding equipment manufacturer.
- Top up the brake fluid level to the maximum mark.
The tire pressure must not exceed 2 bar.
