Body Equipment (1 Of 2) -- Repair (IX)
>>
51 14 Plates, Labels, Adhesive Films
>>
51 14 050 Remove and install the BMW plaque rear
>>
Install the rear plaque
Install the rear plaque
Pull the spray nozzle out of the emblem carefully as pictured.
Attach the plaque
(1)
and lock in place on the snap-in lugs
(2)
.
