Remove headlining
NOTE:
RISK OF DAMAGE
Fold the headlining
Bending of the headlining can result in the need for the headlining to be replaced
Fold the headlining
Bending of the headlining can result in the need for the headlining to be replaced
- Carry out tasks with a second person to assist
- Support the headlining at the front and back
NOTE:
TECHNICAL INFORMATION
The following procedure forms the basis for these repair instructions and must be observed without fail
For ADDITIONAL INFORMATION see: 51 31... General procedure for disassembly/installation of bonded window glass
The following procedure forms the basis for these repair instructions and must be observed without fail
For ADDITIONAL INFORMATION see: 51 31... General procedure for disassembly/installation of bonded window glass
NOTE:
TECHNICAL INFORMATION
Perform window removal using the "spider"
For ADDITIONAL INFORMATION see: 51 31... Window glass removal using "spider"
Perform window removal using the "spider"
For ADDITIONAL INFORMATION see: 51 31... Window glass removal using "spider"
Preliminary work
- Refer to REMOVING THE TRIM PANEL FOR THE REAR LEFT AND RIGHT WATER CHANNEL .
- Refer to REMOVING THE COVERS FOR THE INTERIOR REARVIEW MIRROR .
- Refer to REMOVING A-PILLAR TRIM PANEL, LEFT AND RIGHT .
- Refer to REMOVING THE LEFT AND RIGHT SUN VISOR .
- Refer to REMOVING COUNTER SUPPORTS FOR SUN VISOR ON LEFT AND RIGHT .
- Refer to REMOVING THE FRONT VANITY MIRROR LIGHT .
- Refer to REMOVING THE HANDS-FREE MICROPHONE LEFT AND RIGHT .
- Refer to REMOVING THE ROOF FUNCTION CENTER (FZD) .
- Refer to REMOVING ALL GRAB HANDLES .
- Refer to REMOVING INTERIOR ROOF LIGHT .
- Refer to REMOVING THE LEFT AND RIGHT B-PILLAR TRIM PANELS PARTIALLY .
- Refer to REMOVING BOTH C-PILLAR TRIM PANELS .
- Refer to TRIM OF THE 3RD BRAKE LIGHT .
- Refer to REMOVING THE BRAKE LIGHT .
- Refer to REMOVING REAR WINDOW .
Precondition
The front seats have been fully adjusted towards the bottom
The front seat backrests have been fully adjusted towards the rear
