Install bearing bracket

Coat the O-ring (1) with front axle transmission oil.

Courtesy of BMW OF NORTH AMERICA, INC.
Position the bearing bracket (2) at the engine oil pan.

Tighten down screws (1) .

TIGHTENING TORQUES SPECIFICATION

Bearing bracket to engine oil pan.
M8
	tightening torque	19 Nm

Courtesy of BMW OF NORTH AMERICA, INC.
