Installing the front light combination at the top on the left and right

NOTE: Description is for left component only. Procedure on the right side is identical.

Installing the front light combination at the top

WARNING: Work on components with requirements for a secure energy supply
Ensure proper function after a repair

Lines are allowed to have only one repair area.
Notices in the diagnostic system circuit diagrams must be observed.
When components are replaced, the notices in the applicable BMW parts catalogue must be observed.

Position the front light combination (2) on the bumper cover and lock it correctly in place (arrow).
Tighten the screws (1) .

Courtesy of VOLVO CARS CORPORATION

Follow-up work

Refer to INSTALLING THE FRONT BUMPER COVER .
Refer to PARTIALLY INSTALLING THE FRONT SECTION OF THE FRONT WHEEL ARCH COVER ON THE LEFT AND RIGHT .
Refer to PARTIALLY INSTALLING THE LEFT FRONT AND RIGHT WHEEL ARCH TRIM .
Refer to INSTALLING FRONT ORNAMENTAL GRILLE .
Refer to INSTALLING THE FRONT LEFT AND RIGHT WHEELS .
Refer to INSTALLING THE COVER IN THE ENGINE COMPARTMENT AT TOP LEFT AND RIGHT .
Refer to INSTALLING THE FRONT HOOD SEAL .
