Remove the windshield
NOTE:
RISK OF DAMAGE
Electrostatic discharge .
Damage to or destruction of electrical components .
Electrostatic discharge .
Damage to or destruction of electrical components .
- Leave the electrical components in their original packaging until they are being installed. Only use the original packaging for returning the product. Always package removed components straight away.
- Read and comply with user information on using the associated special tool 12 7 060 .
- Only tap the housings of electrical components. Do not tap pins or multi-pin connectors directly.
- Wear electrically conductive clothing and antistatic shoes (with ESD symbol).
- For additional information see: 61 35... NOTES ON ESD (ELECTROSTATIC DISCHARGE) PROTECTION
NOTE:
RISK OF DAMAGE
Careless handling of tools and sharp-edged components .
Scratches, surface damage .
Careless handling of tools and sharp-edged components .
Scratches, surface damage .
- Protect working area.
- Handle tools and components carefully.
NOTE:
TECHNICAL INFORMATION
The following procedure forms the basis for these repair instructions and must be observed without fail.
For additional information see: General procedure for the disassembly and installation of bonded window glass (X7 2019-2022)
The following procedure forms the basis for these repair instructions and must be observed without fail.
For additional information see: General procedure for the disassembly and installation of bonded window glass (X7 2019-2022)
NOTE:
TECHNICAL INFORMATION
Perform window removal using the "spider".
For additional information see: REMOVING WINDOWS WITH A "SPIDER" (X7 2019-2022)
Perform window removal using the "spider".
For additional information see: REMOVING WINDOWS WITH A "SPIDER" (X7 2019-2022)
Preliminary work
- Refer to REQUIRED NEW PARTS/CONSUMABLES .
- Refer to REMOVING LEFT AND RIGHT GUTTER STRIP OF THE WINDSHIELD .
- Refer to REMOVING THE COVER OF THE ENGINE COMPARTMENT AT THE REAR LEFT .
- Refer to REMOVING THE COVER OF THE REAR RIGHT ENGINE COMPARTMENT .
- Refer to REMOVING LEFT AND RIGHT WIPER ARM .
- Refer to REMOVING THE COWL COVER .
- Refer to REMOVING THE COVERS FOR THE INTERIOR MIRROR .
- Refer to REMOVING THE INTERIOR REARVIEW MIRROR .
- Refer to REMOVING A-PILLAR TRIM PANEL ON THE LEFT AND RIGHT .
- Refer to REMOVING THE KAFAS CAMERA (HIGH-END VERSION) .
- Refer to REMOVING KAFAS CAMERA (MID VARIANT) .
- Refer to DISCONNECTING THE PLUG CONNECTION ON THE RAIN-LIGHT-SOLAR-CONDENSATION SENSOR .
