Attach the spring strut (air suspension) right front

WARNING: This page is about a different car, the 2023 BMW X5, 2022 BMW X5, 2021 BMW X5, 2020 BMW X5, and 2019 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Description is for left component only. Procedure on the right side is identical.

Securing the front spring strut (air suspension strut)

Replace screws (1).
Parts: screw
Position the spring strut on the strut-tower.
Tighten down screws (1).

TIGHTENING TORQUE SPECIFICATIONS

Spring strut/air suspension strut at the front on body
M8 Replace screws.	Tightening torque	28 Nm

Courtesy of BMW OF NORTH AMERICA, INC.
