Remove the lower D-pillar trim panel

• Loosen screws (1).

  Courtesy of BMW OF NORTH AMERICA, INC.

• Have the set of special tools 0 493 752 (00 9 329) ready.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Position suitable special tool between the tailgate seal and the bottom D-pillar trim panel (1).
• Release latch mechanism (2) and unclip the clip (3).
• Feed out the bottom D-pillar trim panel (1) under the sealing lip on the tailgate seal, release upwards out of the guides (4) and remove.

Courtesy of BMW OF NORTH AMERICA, INC.

If installed: Release the Bowden cable for the backrest remote unlocking

• Release and detach the Bowden cable (1) on the bottom D-pillar trim panel (2) in direction of arrow.
• Remove the bottom D-pillar trim panel (2).

Courtesy of BMW OF NORTH AMERICA, INC.
