Mounting both trims for the rear window frame on the side

NOTE: Description is for left component only. Procedure on the right side is identical.

• Check the clips (1) the cover for the side rear window frame (2) for damage; replace if necessary.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Position the cover for the side rear window frame (1) and clip it in on the detents (2).

Courtesy of BMW OF NORTH AMERICA, INC.
