Installing (partial installation) the expansion tank for the charge air coolers

• Position the expansion tank (2)  for the charge air cooler.
• Tighten down screw (1)  .

TIGHTENING TORQUES SPECIFICATION

Low-temperature coolant circuit expansion tank
Tightening torque	screw	2.6 Nm
