Remove headlining
NOTE:
RISK OF DAMAGE
Careless handling of tools and sharp-edged components.
Scratches, surface damage.
Careless handling of tools and sharp-edged components.
Scratches, surface damage.
- Protect working area.
- Handle tools and components carefully.
NOTE:
RISK OF DAMAGE
Electrostatic discharge.
Damage to or destruction of electrical components.
Electrostatic discharge.
Damage to or destruction of electrical components.
- Leave the electrical components in their original packaging until they are being installed. Only use the original packaging for returning the product. Always package removed components straight away.
- Read and comply with user information on using the associated special tool 12 7 060 .
- Only tap the housings of electrical components. Do not tap pins or multi-pin connectors directly.
- Wear electrically conductive clothing and antistatic shoes (with ESD symbol).
- For additional information see: 61 35... NOTES ON ESD (ELECTROSTATIC DISCHARGE) PROTECTION .
NOTE:
TECHNICAL INFORMATION
Perform window removal using the "spider".
For additional information see: 51 31...GENERAL PROCEDURE FOR DISASSEMBLY/INSTALLATION OF BONDED WINDOW GLASS .
Perform window removal using the "spider".
For additional information see: 51 31...GENERAL PROCEDURE FOR DISASSEMBLY/INSTALLATION OF BONDED WINDOW GLASS .
NOTE:
TECHNICAL INFORMATION
The following procedure forms the basis for these repair instructions and must be observed without fail.
For additional information see: 51 31...GENERAL PROCEDURE FOR DISASSEMBLY/INSTALLATION OF BONDED WINDOW GLASS .
The following procedure forms the basis for these repair instructions and must be observed without fail.
For additional information see: 51 31...GENERAL PROCEDURE FOR DISASSEMBLY/INSTALLATION OF BONDED WINDOW GLASS .
Preliminary work
- Refer to REMOVING A-PILLAR TRIM PANEL, LEFT AND RIGHT .
- Refer to REMOVING THE COVERS FOR THE INTERIOR REARVIEW MIRROR .
- Refer to REMOVING INSIDE MIRROR .
- Refer to REMOVING THE KAFAS CAMERA .
- Refer to DISCONNECTING RAIN-LIGHT-SOLAR-CONDENSATION SENSOR .
- Refer to REMOVING THE COVER OF THE ENGINE COMPARTMENT AT THE REAR LEFT .
- Refer to REMOVING THE COVER OF THE REAR RIGHT ENGINE COMPARTMENT .
- Refer to REMOVING LEFT AND RIGHT WIPER ARM .
- Refer to REMOVING LEFT AND RIGHT GUTTER STRIP OF THE WINDSHIELD .
- Refer to REMOVING WINDSHIELD PANEL COVER .
- Refer to REMOVING THE WINDSHIELD .
- Refer to REMOVING THE SUN VISORS AND COUNTER SUPPORT ON THE LEFT AND RIGHT .
- Refer to REMOVING THE ROOF FUNCTION CENTER (FZD) .
- Refer to REMOVING REAR SEAT BENCH .
- Refer to REMOVING LEFT AND RIGHT BACKREST SIDE SECTION .
- Refer to REMOVING RIGHT C-PILLAR TRIM PANEL LEFT AND RIGHT .
- Refer to REMOVING THE INNER DOOR SILL COVER STRIP ON THE LEFT AND RIGHT .
- Refer to REMOVING SIDE TRIM PANEL, REAR LEFT AND RIGHT .
- Refer to REMOVING THE B-PILLAR TRIM PANEL AT LEFT AND RIGHT .
- Refer to TRIMMING OF THE 3RD BRAKE LIGHT .
Precondition
The front seats have been fully adjusted towards the bottom.
The front seat backrests have been fully adjusted towards the rear.
The rear seat backrest is folded down toward the front.
