Remounting the LED fan

NOTE: Description is for left component only. Procedure on the right side is identical.

Removing the LED fan

Loosen screws (1).
Remove protective cap (2).

Courtesy of BMW OF NORTH AMERICA, INC.
Feed out the LED fan (1) in an upwards direction.
Unlock and disconnect connector (2).

Courtesy of BMW OF NORTH AMERICA, INC.

Installing LED fan
Feed in the guide from the LED fan (1) into the intake (2).

Courtesy of BMW OF NORTH AMERICA, INC.
Attach and lock the connector (2) from the LED fan (1).
Ensure correct cable routing in the headlight (3).

Courtesy of BMW OF NORTH AMERICA, INC.
Check the seal (1) of the cover (2) for damage and replace if necessary.

Courtesy of BMW OF NORTH AMERICA, INC.
Position the cover flap (2) on the headlight.

Tighten down screws (1).

TIGHTENING TORQUES SPECIFICATION

Cover cap to headlight
Screw	tightening torque	1.5 Nm
