31 10 Front Axle Mounting
>>
31 10 001 Completely removing and installing front axle with engine and transmission (750i 2016-2019)
>>
Detaching left swivel bearing
Detaching left swivel bearing
Unfasten nut
(1)
.
Remove the screw
(2)
.
Remove the right swivel bearing from the wishbone
(3)
.
Courtesy of BMW OF NORTH AMERICA, INC.
