Install luggage compartment wheel arch trim panel, left
Install luggage compartment wheel arch trim panel, left
Feed in the luggage compartment wheel arch trim panel over the retaining clip (3) and position.
Feed in the luggage compartment wheel arch trim panel under the sealing lip of the tailgate seal.
Clip in the clip (2) and fasten the expanding rivets (1).
Courtesy of BMW OF NORTH AMERICA, INC.
