Removing air duct radiator
Preliminary work
- Refer to DEACTIVATING THE 48 V ELECTRICAL SYSTEM .
- Refer to DISCONNECTING ALL BATTERY GROUND LEADS .
- Refer to REMOVING SEAL FOR FRONT HOOD .
- Refer to REMOVING THE COVER FOR THE CENTER ENGINE COMPARTMENT .
- Refer to REMOVING CENTER RADIATOR ORNAMENTAL GRILLE .
- Refer to PARTIALLY RELEASING THE FRONT LEFT AND RIGHT WHEEL ARCH TRIM PANELS .
- Refer to PARTIALLY REMOVING TEMPERATURE SENSOR .
- Refer to REMOVING THE BOTTOM FRONT LEFT AND RIGHT COVER .
- Refer to REMOVING THE FRONT UNDERBODY PROTECTION .
- Refer to REMOVING FRONT BUMPER COVER .
- Refer to REMOVE TOP AUTOMATIC AIR FLAP CONTROL .
- Refer to IF INSTALLED: REMOVING FRONT RADAR SENSOR (FRS) WITH BRACKET .
- Refer to REMOVING THE BOTTOM AUTOMATIC AIR FLAP CONTROL .
- Refer to REMOVING PEDESTRIAN PROTECTION SENSOR .
- Refer to REMOVING THE LEFT AND RIGHT FANFARE HORN .
- Refer to REMOVE STIFFENING STRUT .
- Refer to REMOVING LEFT AND RIGHT BRAKE AIR DUCT .
- Refer to REMOVING INTAKE SILENCER HOUSING .
- Refer to REMOVING INTAKE PORT .
NOTE:
The operations shown only for one side must be carried out on both sides.
