Installing the lower wheel arch cover on the left and right

NOTE: Description is for left component only. Procedure on the right side is identical.

Removing the lower wheel arch cover

Tighten down screws (2).

TIGHTENING TORQUE SPECIFICATION

Lower side cover at front
Hexagon screw for thermoplastic	Tightening torque	3 Nm

Courtesy of BMW OF NORTH AMERICA, INC.
