Releasing the wiring harness section on the left shock tower
Releasing the wiring harness section on the left shock tower
Feed out the cable linkage (1) of the hood and set it aside.
Loosen clamps (2).
Feed out wiring harness section (3) on the left shock tower and set aside.
