Remove the windshield
NOTE:
RISK OF DAMAGE
Electrostatic discharge.
Damage to or destruction of electrical components.
Electrostatic discharge.
Damage to or destruction of electrical components.
- Leave the electrical components in their original packaging until they are being installed. Only use the original packaging for returning the product. Always package removed components straight away.
- Read and comply with user information on using the associated special tool 12 7 060.
- Only tap the housings of electrical components. Do not tap pins or multi-pin connectors directly.
- Wear electrically conductive clothing and antistatic shoes (with ESD symbol).
- For additional information see: 61 35.. NOTES ON ESD (ELECTROSTATIC DISCHARGE) PROTECTION .
NOTE:
RISK OF DAMAGE
Careless handling of tools and sharp-edged components.
Scratches, surface damage.
Careless handling of tools and sharp-edged components.
Scratches, surface damage.
- Protect working area.
- Handle tools and components carefully.
NOTE:
TECHNICAL INFORMATION
The following procedure forms the basis for these repair instructions and must be observed without fail.
For additional information see: 51 31..GENERAL PROCEDURE FOR THE DISASSEMBLY AND INSTALLATION OF BONDED WINDOW GLASS
The following procedure forms the basis for these repair instructions and must be observed without fail.
For additional information see: 51 31..GENERAL PROCEDURE FOR THE DISASSEMBLY AND INSTALLATION OF BONDED WINDOW GLASS
NOTE:
TECHNICAL INFORMATION
Perform window removal using the "SPIDER ".
Perform window removal using the "SPIDER ".
Preliminary work
- Refer to REQUIRED NEW PARTS/CONSUMABLES .
- Refer to REMOVING LEFT AND RIGHT GUTTER STRIP OF THE WINDSHIELD .
- Refer to REMOVING THE COVER OF THE ENGINE COMPARTMENT AT THE REAR LEFT .
- Refer to REMOVING THE COVER OF THE REAR RIGHT ENGINE COMPARTMENT .
- Refer to REMOVING LEFT AND RIGHT WIPER ARM .
- Refer to REMOVING THE COWL COVER .
- Refer to REMOVING THE COVERS FOR THE INTERIOR MIRROR .
- Refer to REMOVING THE INTERIOR REARVIEW MIRROR .
- Refer to REMOVING A-PILLAR TRIM PANEL ON THE LEFT AND RIGHT .
- Refer to REMOVE THE KAFAS CAMERA (HIGH-END VERSION) .
- Refer to REMOVING KAFAS CAMERA (MID VARIANT) .
- Refer to DISCONNECTING THE PLUG CONNECTION ON THE RAIN-LIGHT-SOLAR-CONDENSATION SENSOR .
