Install the reinforcement strut on the right engine mount

NOTE: Only perform the operation on the right side.

• Position the reinforcement strut (1).
• Screw in the screw (2) by hand force.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Tighten down screw (1).

TIGHTENING TORQUE SPECIFICATION

Engine mount reinforcement strut on body
M8	Tightening torque	28 Nm

Courtesy of BMW OF NORTH AMERICA, INC.

• Tighten the screw (2) at the reinforcement strut (1).

TIGHTENING TORQUE SPECIFICATION

Engine mount reinforcement strut on front subframe
M8	Tightening torque	28 Nm

Courtesy of BMW OF NORTH AMERICA, INC.
