16 14 500 Removing and installing or replacing control unit for electric fuel pump

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2017 BMW X3, 2016 BMW X3, 2015 BMW X3, 2014 BMW X3, and 2013 BMW X3. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Read and comply with notes on PROTECTION AGAINST ELECTROSTATIC DAMAGE (ESD protection).

Necessary preliminary work:

Remove REAR SEAT .

Disconnect plug connection (1).

Loosen the nuts (2) and remove control unit for the electronic fuel pump.

Installation note:

Tightening torque: 16 14 1AZ .

Fig 1: Identifying Electronic Fuel Pump, Plug Connection And Nut

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Carry out programming/encoding
