26 12 011 Replacing Grooved Ball Bearing In Centre Mount Of Propeller Shaft

WARNING: This page is about a different car, the 2002 BMW M Roadster, 2002 BMW M Coupe, 2001 BMW M Roadster, and 2001 BMW M Coupe. However, it is still accessible from the selected car via links, so may be relevant.

Remove center mount, refer to 26 12 001 REPLACING COMPLETE PROPELLER SHAFT CENTER BEARING - VERSION WITH SLIDE or 26 12 001 REPLACING COMPLETE PROPELLER SHAFT CENTRE MOUNT - VERSION WITHOUT SLIDE .

Press out grooved ball bearing with Special Tool 23 1 160.

Fig 1: Pressing Out Grooved Ball Bearing

Courtesy of BMW OF NORTH AMERICA, INC.

Always coat center mount in area of ball bearing with Circolight.

Press in ball bearing as far as stop using a suitable sleeve.

Fig 2: Pressing In Ball Bearing

Courtesy of BMW OF NORTH AMERICA, INC.
